TPU 85A

BEDROCK 3D TPU 85A delivers a high degree of flexibility, a broad range of degrees of hardness in different designs, without compromising on strength or durability. It’s ideal for functional parts in footwear, sports, and leisure, as well as industrial, automotive, agricultural, and construction applications. Whether you need flexible components that absorb impact or durable parts that handle mechanical stress, TPU 85A provides consistent, reliable performance. Trouble free printing due to high diameter consistency.

It comes in its natural white color. Chemical properties (e.g. resistance against particular substances) and tolerance for solvents can be made available, if these factors are relevant for a specific application. Generally, these properties correspond to publicly available data on polyether based TPUs. This material is not FDA conform.

Material Highlights

• High wear and abrasion resistance
• Very good low-temperature flexibility
• High tensile strength and outstanding resistance to tear propagation
• Excellent damping characteristics
• High resistance to oils, greases, oxygen and ozone
• Biocompatible

• Functional flexible parts
• Footwear
• Sports & Leisure
• Automotive
• Industrial Manufacturing
• Agriculture
• Construction

• Nozzle Temperature: 200-220 °C
• Build Chamber Temperature: -
• Bed Temperature: 40 °C
• Bed Material: Glass
• Nozzle Diameter: ≥ 0.4 mm
• Print Speed: 15-168 mm / s**

** To achieve faster printing speeds, it may be necessary to raise the nozzle temperature. The highest speed mentioned has been determined through our latest tests, ensuring optimal surface quality with a 0.6mm nozzle and 0.24mm layer height. layer height. Please note that as printing technology and equipment evolve, we anticipate the possibility of achieving even faster speeds in the future.

We’ve got you covered with ready-to-go print profiles, just download and start creating.

• Shore A Hardness: 85
• Abrasion resistance: 82mm3
• Compression set at 23°C, 72 h: 26%
• Stress at break: 34 MPa (XY), 10 MPa (ZX)
• Elongation at Break, Strain at Break: 600% (XY), 320 % (ZX)
• Tear strength: 80 kN/m (XY), 18 kN/m (XZ), 30 kN/m (ZX)
