PPSU

BEDROCK 3D PPSU pushes the boundaries of what’s possible with FFF printing. While other polymers may fail under high heat or harsh environments, PPSU maintains strength, safety, and stability. That’s why it’s a go-to choice for aerospace, railway, and advanced industrial applications. From sterilizable medical tools to components exposed to hot fluids or demanding conditions, PPSU ensures your designs perform where it matters most.

The BASF Ultrason® resins are amorphous thermoplastics derived from polyethersulfone (PESU), polysulfone (PSU) and poly- phenylsulfone (PPSU) and ensure very high thermal resistance. BEDROCK 3D PPSU can be succesfully utilized in applications where other plastics, such as polyamide, polycarbonate, polyoxymethylene and polyalkylene terephthalates, fail to meet performance specifications.

Material Highlights

• Inherently flame-retardant with V0 classification according to UL 94 (@1.5mm and 3.0mm)
• Short-term temperature resistance up to 220°C; long-term service temperature resistance up to 180°C
• Manufactured from food-contact-approved raw materials
• High dimensional stability with excellent creep strength at high temperatures
• Resistant to hot water, coolants, oils (up to 170°C), fuels, fluorine, and dishwasher detergents
• Meets railway classification EN 45545-2 standards

• Ideal for autoclaving processes (hot steam sterilization at 134°C)
• Aerospace and railway industries
• Applications exposed to high temperatures
• Food contact applications requiring high-temperature resistance and compatibility with dishwasher detergents
• Support material for high-temperature 3D printing materials, such as PEI-based materials like ULTEM™ 9085

• Nozzle Temperature: 210-230 °C
• Build Chamber Temperature: -
• Bed Temperature: 50 - 70 °C
• Bed Material: Glass
• Nozzle Diameter: ≥ 0.4 mm
• Print Speed: 40-80 mm /

We don't have any print profiles available at the moment, please contact us if you need any support.

• Tensile Strength (MPa): 49.0 (ZX), 74.5 (XY)
• Elongation at Break: 2.9% (ZX), 7.3% (XY)
• Flexural Modulus (MPa): 1700 (ZX), 1910 (XZ), 1940 (XY)
• Impact Strength, Izod Notched (kJ/m²): 5.3 (ZX), 15.8 (XZ), 13.7 (XY)
• Impact Strength, Izod Unnotched (kJ/m²): 21.0 (ZX), no break (XZ), no break (XY)
• HDT @ 0.45 MPa: 215°C
